| 19 p. | Shumskayte M.Y., Yanushenko T.A., Golikov N.A. |
| Study of permafrost rocks of the Bykov peninsula by laboratory methods of dielectric spectroscopy and nuclear magnetic resonance | |
| The complex permittivity of sedimentary rocks mainly depends on the porosity and water saturation. For frozen rocks, the complex permittivity is also determined by the state of water in the pores. This is due to the difference in permittivity and electrical conductivity of free water and ice in the pores of the rock. In fine-porous rocks, the influence of bound water is great, the properties of which differ from the properties of free water. A study of the granulometric composition and specific electrical resistance of rocks was carried out on samples of permafrost rocks, and measurements were also made using the nuclear magnetic resonance method. Nuclear magnetic resonance is widely used in geological and geophysical studies to determine the filtration-capacitive properties of rocks and the rheological properties of formation fluids. It was found that the transformation of water into ice with a decrease in temperature does not occur at a certain temperature, but in a certain range of negative temperatures. It was found that the dielectric constant changes by approximately 6 for different wells. According to NMR data, a connection was established between water saturation and granulometric composition and the dependence of the transverse relaxation time on the degree of mineralization and temperature of rocks. Keywords: complex permittivity, NMR relaxometry, permafrost rock, Bykov peninsula. |
|
| article citation | Shumskayte M.Y., Yanushenko T.A. Golikov N.A. Izuchenie mnogoletnemerzlykh porod Bykovskogo poluostrova laboratornymi metodami dielektricheskoy spektroskopii i yadernogo magnitnogo rezonansa [Study of permafrost rocks of the Bykov peninsula by laboratory methods of dielectric spectroscopy and nuclear magnetic resonance]. Neftegazovaya Geologiya. Teoriya I Praktika, 2025, vol. 20, no. 1, available at: https://www.ngtp.ru/rub/2025/8_2025.html EDN: OORYLZ |
