Khudoley A.K.

Graduated from Leningrad State University (1979), specialization "geologist tenant search engine".
PhD in geology and mineralogy.
Professor of St. Petersburg State University.
Area of scientific interest: structural geology, tectonics, sedimentary basins.
Author of 180 publications.
Geological simulation and issues of petroleum fields development
Section editor – PhD in geology and mineralogy Prischepa O.M.
Article # 20_2015 submitted on 05/18/2015 displayed on website on 06/01/2015
16 p.
pdf  Reconstruction of kinematic characteristics of faults and paleostress field of the Urman-Archinsk area (Nyurolsk depression)
Paleostress field reconstruction methods based on study of structural maps of seismic horizons with the following interpretation of displacement vector on the fault surface as slickenline and slickenside is also suggested. Estimation of the main axes of the stress field was done using two softwares (FaultKin and StressGeol), which are based on different theoretical assumptions on the media properties and relationship between brittle fractures and stress field. In Mesozoic compression, the north-northwest trend axis had predominated. Shallow to moderate dipping of the main compression and extension axes points to predominance of strike-slip tectonics at that stage of the Urman-Archinsk area evolution. During formation of the surface that separate Paleozoic carbonates and Mesozoic clastic rocks (seismic horizon M1) normal fault displacements were significant showing that during Mesozoic there were several stages of the fault activity.

Keywords: seismic horizons, stress field, strike-slip faults, Urman-Archinsk area.
article citation Moskalenko A.N., Khudoley A.K., Zhukov V.V., Demin V.Yu., Verin A.V. Rekonstruktsiya kinematicheskikh kharakteristik razryvnykh narusheniy i polya paleonapryazheniy dlya Urmano-Archinskoy ploshchadi (Nyurol'skaya vpadina) [Reconstruction of kinematic characteristics of faults and paleostress field of the Urman-Archinsk area (Nyurolsk depression)]. Neftegazovaya Geologiya. Teoriya I Praktika, 2015, vol. 10, no. 2, available at:

   Allmendinger R.W., Cardozo N.C., Fisher D., Structural geology algorithms: Vectors & Tensors. Cambridge, Cambridge University Press, 2012, 302 p.
   Balakina L.M., Vvedenskaya A.V., Golubeva I.V., Misharina L.A., Shirokova E.I. Pole uprugikh napryazheniy Zemli i mechanism ochagov zemletryaseniy [Elastic stress field of the Earth and mechanics of earthquakes]. Moscow, Nauka, 1972, 192 p.
   Gartrell A.P. Potential new method for paleostress estimation by combining three-dimensional fault restoration and fault slip inversion techniques: First test on the Skua Field, Timor Sea. AAPG Hedberg Series, 2005, no. 2, p. 23–36.
   Gzovskiy M.V. Osnovy tektonofiziki [Basics of tectoniophysics]. Moscow, Nauka, 1975, 536 p.
   Kostrov B.V. Mekhanika ochaga tektonicheskogo zemletryaseniya [Mechanics of the tectonic earthquakes]. Moscow, Nauka, 1975, 176 p.
   Marrett R., Allmendinger R. Kinematic analysis of fault-slip data. Journal of Structural Geology. 1990. vol. 12, p. 973-986.
   Morris A.P., Ferrill D.A. The importance of the effective intermediate principal stress (?2) to fault slip patterns. Journal of Structural Geology, 2009, vol. 31, p. 960-959.
   Morris A.P., McGinnis R.N., Ferrill D.A. Fault displacement gradients on normal faults and associated deformation. AAPG Bulletin, 2014, v. 98, p. 1161–1184.
   Parfenov V.D. Analiz napryazhennogo sostoyaniya v angidridovykh tectonitakh [Stress state analysis of the anhydrite tectonites]. DAN SSSR, 1981, vol. 260, no. 3, p. 695-698.
   Parfenov V.D. K metodike tectonofizicheskogo analiza geologicheskikh structur [On the method of tectonophysic analysis of geological structures]. Geotektonika, 1984, no. 1, p. 60-72.
   Rebetsky Yu.L. Razvitie metoda kataklasticheskogo analiza skolov dlya otsenki velichin tectonicheskikh napryazheniy [Development of the method of cataclastic analysis of shear fractures for tectonic stress estimation]. Doklady RAN, 2003, vol. 388, no. 2, p. 237-241.
   Rebetsky Yu.L. Rekonstruktsiya tectonicheskikh napryazheniy i seismotektonicheskikh deformatsiy: metodicheskie osnovy, pole sovremennykh napryazheniy Yugo-Vostochnoi Azii i Okeanii [Reconstruction of tectonic stress and seismotectonic deformation: methods, modern stress field in the South-East Asia and Oceania]. Doklady RAN, 1997, vol. 354, no. 1, p. 101-104.
   Rebetsky Yu.L. Tectonicheskie napryazheniya i prochnost prirodnykh massivov [Tectonic Stresses and Strength of Rock Massifs]. Moscow, Akademkniga, 2007, 406 p.
   Sherman S.I., Dneprovskiy Yu.I. Polya napryazheniy zemnoi cory i geologo-structurnye metody ikh issledovaniya [Stress fields in the Earth’s crust and structural methods of their study]. Novosibirsk, Nauka, 1989, 158 p.
   Uemura T., Mitsutani Sh. Geologicheskie struktury [Geological structures]. Moscow, Nedra, 1990, 292 s.
